Vertical Injection Molding Machine JTT-850

Clamping force: 85T
Max shot volume: 373CM3
Vertical injection, vertical clamping
Availability:
Quantity:
  • JTT-850

  • JINTONG


Model
         JTT-850
injection systemScrew   Diametermm  35    40    45    50
Injection Pressurekg/cm2 2171  1663  1314  1064
Theoretical Shot Volumecm3  183   238  302   373
Injection Ratecm3/sec   82   107  135   167
Screw Strokemm           190
Screw Speedrpm          0-200
Nozzle Contact Forcetons           2.9
Nozzle Strokemm           220
Number of Temperature Control-            4
Hopper CapacityL           30
clamping systemClamping   Forcetons           85
Opening Forcetons          10.5
Platen Sizemm         740x500
Distance Between Tie Barmm         560x320
Min Mold Heightmm         250/200
Opening Strokemm          250
Max Open Daylightmm        500/450
Ejector Forcetons        3.3/3.5
Ejector Strokemm         75/145
oil pressure systemMax   Hydraulic Pressurekg/cm2          140
Pump OutputL/min          76
Oil Reservior CapacityL         180
Cooling Water Consumption/hr       1200-1500
Pump Moter PowerKW          11
Barrel Heating Powerkw         5.6
Total Powerkw         16.6
otherMachine   Weighttons         4.5
Machine Dimensionmm    1.8*1.30*3.01
Shipping Weighttons         4.7
Shipping Measurementmm    1.9*1.40*3.11


Vertical injection molding machine JTT-850

Clamping force: 85T

Max shot volume: 353cm3


vertical injection vertical clamping                                                                                 screw injection unit

Precision designs on machine: 2 or 3 section temperature control, stepless adjustment for injection rate, back pressure and screw speed

Fixed down platen with movable up platen is good for insert parts to position, as well as ejector unit for finished products

Low pressure opening mold unit to protect mold safty

Optional single slide table or double slide table to improve productivity and efficiency
