JT-250 HS
JINTONG
| Model | JT-250 | ||
| injection system | Screw Diameter | mm | 20 25 30 32 |
| Injection Pressure | kg/cm2 | 1997 1287 886 800 | |
| Theoretical Shot Volume | cm3 | 32 49 70 85 | |
| Max Shot Weight | g | 29 45 64 72 | |
| Injection Rate | cm3/sec | 30 47 68 80 | |
| Screw Stroke | mm | 100 | |
| Screw Speed | rpm | 0-205 | |
| Nozzle Contact Force | tons | 2.6 | |
| Nozzle Stroke | mm | 165 | |
| Number of Temperature Control | - | 1+2 | |
| Hopper Capacity | L | 20 | |
| clamping system | Clamping Force | tons | 30 |
| Opening Force | tons | 6.5 | |
| Platen Size | mm | 520x370 | |
| Distance Between Tie Bar | mm | 350x200 | |
| Min Mold Height | mm | 160/100 | |
| Opening Stroke | mm | 180 | |
| Max Open Daylight | mm | 340/280 | |
| Ejector Force | tons | 1.3 | |
| Ejector Stroke | mm | 35 | |
| oil pressure system | Max Hydraulic Pressure | kg/cm2 | 140 |
| Pump Output | L/min | 26 | |
| Oil Reservior Capacity | L | 100 | |
| Cooling Water Consumption | /hr | 400-600 | |
| Pump Moter Power | KW | 4 | |
| Barrel Heating Power | kw | 2.7 | |
| Total Power | kw | 6.7 | |
| other | Machine Weight | tons | 1.1 |
| Machine Dimension | mm | 1570*950*2350 | |
| Shipping Weight | tons | 1.3 | |
| Shipping Measurement | mm | 1670*1050*2450 | |
