Vertical Injection Molding Machine JTT-450

Clamping force: 45T
Max shot volume: 115CM3
Vertical injection, vertical clamping
Availability:
Quantity:
  • JTT-450

  • JINTONG


Model
       JTT-450
injection systemScrew   Diametermm  20     30      35
Injection Pressurekg/cm22509    1742    1280
Theoretical Shot Volumecm3 59      85      115
Max Shot Weightg 54      77      105
Injection Ratecm3/sec 36      52       71
Screw Strokemm120
Screw Speedrpm0-190
Nozzle Contact Forcetons2.4
Nozzle Strokemm180
Number of Temperature Control-3
Hopper CapacityL20
clamping systemClamping   Forcetons45
Opening Forcetons8.3
Platen Sizemm580x430
Distance Between Tie Barmm400x250
Min Mold Heightmm210/150
Opening Strokemm200
Max Open Daylightmm410/350
Ejector Forcetons1.3
Ejector Strokemm45/95
oil pressure systemMax   Hydraulic Pressurekg/cm2140
Pump OutputL/min39
Oil Reservior CapacityL130
Cooling Water Consumption/hr600-800
Pump Moter PowerKW5.5
Barrel Heating Powerkw3.5
Total Powerkw9
otherMachine   Weighttons1.4
Machine Dimensionmm1.66*1.17*2.34
Shipping Weighttons1.6
Shipping Measurementmm1.76*1.27*2.44


Vertical injection molding machine JTT-450

Clamping force: 45T

Max shot volume: 115cm3


vertical injection vertical clamping                                                                                 screw injection unit

Precision designs on machine: 2 or 3 section temperature control, stepless adjustment for injection rate, back pressure and screw speed

Fixed down platen with movable up platen is good for insert parts to position, as well as ejector unit for finished products

Low pressure opening mold unit to protect mold safty

Optional single slide table or double slide table to improve productivity and efficiency




2012050874113065
