JT-150
JINTONG
| Model | JT-150 | ||
| injection system | Screw Diameter | mm | 20 25 |
| Injection Pressure | kg/cm2 | 1715 1098 | |
| Theoretical Shot Volume | cm3 | 31 49 | |
| Max Shot Weight | g | 29 45 | |
| Injection Rate | cm3/sec | 20 30 | |
| Screw Stroke | mm | 100 | |
| Screw Speed | rpm | 0-215 | |
| Nozzle Contact Force | tons | - | |
| Nozzle Stroke | mm | - | |
| Number of Temperature Control | - | 1+2 | |
| Hopper Capacity | L | 15 | |
| clamping system | Clamping Force | tons | 15 |
| Opening Force | tons | 7 | |
| Platen Size | mm | 450x280 | |
| Distance Between Tie Bar | mm | 265 | |
| Min Mold Height | mm | 100/40 | |
| Opening Stroke | mm | 160 | |
| Max Open Daylight | mm | 260/200 | |
| Ejector Force | tons | 1.3 | |
| Ejector Stroke | mm | 35 | |
| oil pressure system | Max Hydraulic Pressure | kg/cm2 | 140 |
| Pump Output | L/min | 19.3 | |
| Oil Reservior Capacity | L | 80 | |
| Cooling Water Consumption | /hr | 400-600 | |
| Pump Moter Power | KW | 2.2 | |
| Barrel Heating Power | kw | 2 | |
| Total Power | kw | 4.2 | |
| other | Machine Weight | tons | 0.5 |
| Machine Dimension | mm | 1380*850*2100 | |
| Shipping Weight | tons | 0.7/0.75 | |
| Shipping Measurement | mm | 1480*950*2200 | |
