Vertical Injection Molding Machine JTKR-2500R

Clamping force: 250T Max shot volume: 1116cm3 Horizontal injection vertical clamping rotary table

		UNIT	JTKR-2500R
INJECTION SYSTEM	screw diameter	mm	55 60 65 70
	injection pressure	kg/cm²	1979 1663 1416 1221
	theoretical shot volume	cm³	698 820 962 1116
	injection rate	cm3/sec	238 283 312 385
	screw stroke	mm	290
	screw speed	rpm	0-250
	temprature control number	-	6
CLAMPING SYSTEM	clamping force	tons	250
	opening force	tons	22.2
	min mould height	mm	300
	opening stroke	mm	400
	max open daylight	mm	700
	rotary table size	mm	1500
	distance between tie bar	mm	630*630
	nozzle center height	mm	150±50
	min distance between nozzle and mold shot gate	mm	160
	ejector force	tons	5.1
	ejector stroke	mm	80
OIL PRESSURE SYSTEM	max hydraulic pressure	kg/cm²	140
	pump output	L/min	200
	oil reservoir capacity	L	500
	cooling water consumption	/hr	1200-1600
	pump motor power	KW	30
	heating power	kw	14.5
	total power	kw	44.5
OTHER	machine weight	tons	17.2
	machine dimension	m	5.52.53.2
	machine dimension	m	5.52.53.2
